Usage: | Laundry | Application: | Dormitory, Resue, Checking Room |
---|---|---|---|
Life Span: | 20 Years | Window: | Aluminium |
Door: | Slide Door | Color: | Blue, White, Red, Green, And Others Customers Can Customize |
High Light: | luxury container homes,ready made shipping container homes |
5 separate rooms 40 HQ rescue worker living container with Sound proof and thermal insulation function
Specification
1 | frame | color: black | 4mm floor frame+3mm roof frame+4mm column+corner | 1 | set |
2 | roof | exterior sheet | shipping container plate 2.0mm | 1 | set |
galvanzied c purlin | 3.0mm(C100*50*20) | 1 | set | ||
rockwool insulation | 100mm,70KG/M3 | 1 | set | ||
decorative ceiling | 0.4mm | 1 | set | ||
3 | floor | composit wood floor | 12mm | 1 | set |
fiber cement | 12mm fiber cement | ||||
rockwool insulation | 100mm,70KG/M3 | 1 | set | ||
color steel sheet | 0.5 color painted steel plate | 1 | set | ||
4 | wall | exterior sheet | shipping container plate 2.0mm | 1 | set |
galvanzied sqaure tube | 40*60*2.0mm | 1 | set | ||
rockwool insulation | 100mm,70KG/M3 | 1 | set | ||
composit wood sheet | composite wood floor | 1 | set | ||
wall background(PMMA) | lumber core with PMMA PICTURE | 1 | set | ||
5 | door | door | 2438*2591 | 1 | set |
6 | electricity system | distribution box | 1 | set | |
industrial socket and plug | voltage 220/400V,50Hz, 3/5 极, 32A | 1 | set | ||
ceiling lamp | 18w | 6 | pcs | ||
socket(AC) | 16A three holes | 1 | set | ||
socket(wall) | 10A five holes | 2 | set | ||
light switch | 2 | set | |||
electricity wire | wire | 1 | set | ||
hydraulic system | 1 | set | |||
7 | sealent | strucural adhesive | each slab joint | 1 | set |
polyfoam adhesive | window&door opening | ||||
silicon sealant | window&door opening | ||||
8 | decorative line | concave line+skirting line | PVC skirting line | 1 | set |
9 | accidential expense | labor cost+welding material+depletion | 1 | ||
11 | Toliet | 5 | sets | ||
12 | Mirrow | wooden | 1 | set | |
13 | wash basin (inlet&outlet) | 1 | set |
