| Place of Origin: | China |
|---|---|
| Brand Name: | Sussman |
| Certification: | CE; ISO |
| Model Number: | SU-LG26 |
| Minimum Order Quantity: | 50 square meters |
| Price: | USD180-USD250 per square meter |
| Packaging Details: | plastic film |
| Supply Ability: | 500 square meter per week |
| Name: | Prefabricated Light Steel Frame House | Material: | Light Gauge Steel/ OSB Board/ Fiberglass Insulation/ FC Board/ Plaster Board |
|---|---|---|---|
| Door: | Aluminum Alloy Sliding Doors | Window: | Alu. Alloy Frame Double Glass |
| Wind-proof: | Maximum 60 Meters Per Second | Water And Heat Insulation: | 100 Mm In Thickness |
| High Light: | light steel frame homes,light steel structure house |
||
Light Steel Frame Luxury Prefab House Building Prefabricated Villa Light Steel Prefabricated Maison Home
1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.
the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis : 89mm light gauge steel flooring chassis
4. flooring: 18mm fiber cement board with vapor barrior and bamboo flooring or wooden flooring , pvc carpet etc.
5. Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration
6. interior lining: 9m fiber cement board ,water-proof ,termite-proof ,security and healthy
7. ceiling: 8mm pvc ceiling panel
8. insulation: 89mm glasswool insulation with good sound proof performance.
9. windows: PVC sliding windows
10. exterior door: high quality aluminim sliding windows
11. interior door: painted wood door
12. bathroom: shower, wash basin, toilet inculded
13. roofing: corrugated steel roofing with gutter system
14. veranda deck: W.P.C veranda flooring
| Name | Description | Specifications |
| Steel frame | Color | As you required |
| Roof | Roof covering | 0.45mm thickness color steel sheet, white grey |
| Insulation | 100mm thickness glass wool, 12kg/m3, single faced aluminum foil | |
| Ceiling | YX12-110-880 flashing steel sheet, 0.35mm thickness, white grey | |
| Floor | Sub-floor | 0.3mm thickness color steel sheet |
| Insulation | 100mm thickness glass wool, 12kg/m3, single faced aluminum foil | |
| Floor | 18mm Glass Magnesium Board 1.6mm PVC floor (blue) | |
| Wall panels | Sandwich panel with EPS insulation | double faced 0.4mm color steel panel, 75mm insulation, 16kg/m3, |
| Window | Upvc window frame and sliding widow | White 1120*1100mm, hollow glass, with aluminum alloy rails |
| Door | Steel door | Right-hand inward-opening door, 845*2035mm |
| Electrics system | CEE industrial socket | 220V, 50Hz, three phase, 32A |
