Portable Prefabricated Container House For Labour Residential Accommodation

Portable Prefabricated Container House For Labour Residential Accommodation
Portable Prefabricated Container House For Labour Residential Accommodation Portable Prefabricated Container House For Labour Residential Accommodation Portable Prefabricated Container House For Labour Residential Accommodation Portable Prefabricated Container House For Labour Residential Accommodation
Basic Information
Place of Origin: China
Brand Name: Sussman
Certification: CE; ISO
Model Number: SU-PH
Minimum Order Quantity: One 20 GP
Price: USD4500 per peice
Packaging Details: plastic film
Delivery Time: 10-15 days
Payment Terms: L/C, D/P, T/T, D/A
Supply Ability: 100 pieces per month
Contact Now
Type: Prefab House Wind Resistance: Grade 8
Design: Professional Architect Drawing Roof&wall Material: Fiberglass Rock Wool Sandwich Panel
Lifespan: 10-15 Years Window: Aluminum Or PVC Frame With Clear Glass
High Light:

prefab metal house kits

,

prefabricated metal homes

Portable Steel Structure Knockdown Prefab House For Labour Residential Accommodation



Item Name
Material
Specification
Unit
Dimension

13.0*8.9*7.023
m3
column 1
Q235B
200*200*6.0mm square tube
T
column 2
Q235B
100*100*3.0mm square tube
T
column 3
Q235B
80*80*2.0mm square tube
T
canopy beam
Q235B
80*80*2.0 square tube
T
roof frame beam
Q235B
C80*35*15*2+50 square tube
T
flooring beam
Q235B
HN298x149x5.5x8mm
T
roof purlin
Q235B
C80*35*15*2
T
flooring purlin
Q235B
HN248x124x5.5x8mm
T
ring beam
Q235B
80*80*2 square tube
T
free supporting
Q235B
L50*3.0
T
gusset plate
Q235B

T
material loss
Q235B
5%
T
component making

includes the cutting, welding, painting, etc
T
component paint

coating painting
T
roof panel

L*960*50mm rock wool sandwich panel with 0.5mm color steel sheet (Huaguan brand)
㎡
external wall panel

L*950*50mm rock wool sandwich panel with 0.5mm color steel sheet (Huaguan brand)
㎡
partition wall panel

L*950*50mm rock wool sandwich panel with 0.426mm color steel sheet (normal brand)
㎡
sandwich panel cutting charge


㎡
steel decking

1000-50-0.8
㎡
L shape block materials for the steel decking

galvanized
m
glass wall

13000*2400H
㎡
manual rolling door

1600*2400H
㎡
aluminm sliding windows 1

double glazing glass. 1130*1000H*8 pc
㎡
aluminm sliding windows 2

1130*1000*1 pc
㎡
aluminm sliding windows 3

1130*1000*2 pc
㎡
aluminm sliding windows 4

600*600 for toilet
set
steel door

880*2040*8 pc
set
sandwich panel door

750*2000*4 pc for toilet
set
stair

with handrail
set
flashing materials

Steel plate bending, self tapping screw, Latin, silica gel, etc
㎡
galvanized groove

for fixed the panles
m
chemical screws

M20
set
high strength screw

M20
set



Portable Prefabricated Container House For Labour Residential Accommodation 0Portable Prefabricated Container House For Labour Residential Accommodation 1Portable Prefabricated Container House For Labour Residential Accommodation 2
