Type: | Light Steel Prefab House | Application: | Steel Fabricated House |
---|---|---|---|
Structure: | Galvanized Steel Frame | Size: | No Less Than 60m2 |
Keyword: | Moduler Homes, Log Cabin, Container House, Container Homes 40ft Luxury Houses, Prefab House | Life Span: | 70 Years |
High Light: | light steel frame homes,modern steel structure homes |
Thermal insulation light Steel Prefab House thickness 1.0 for the stud framing
Subject structure
The steel structure system adopts G550 steel, 1.0-1.8 mm thin-walled light steel keel system, and the structural connectors adopt 2.0 mm thick galvanized steel firmware.
Design parameters
Roof live load: 0.6kn/m2
Wind load: 30m-50m/s
Seismic Intensity: 9 Degrees
Service life: 50 years
Wall | BMT- high Strength Aluminized Zinc Keel | 90*38*0.8 |
Exterior Wall | PVC wall | customized color and texture |
Exterior Wall Base Plate | OSB base plate | 1.22*2.44*0.9 |
Interior Wall | Plasterboard | 1.22*2.44*12 |
Interior Wall Paint | putty,emulsion paint | floor space *3 |
Reflecting Layer | waterproof and breathable membrane | |
Roof Panel | OSB base plate | 1.22*2.44*0.9 |
Roof Waterproof | SBS waterproof roll | full coverd |
Roof | asphalt roofing shingle | customized |
Top Ceiling | plasterboard | 1.22*2.44*0.9 |
Cornice Hanging Eaves | PVC customized | customized |
Drainage System | PVC tube | centralized drainage |
Door | Entry Door | security door (single passage door) |
Window | aluminum alloy window (hollow and tempered) | Customized |
Interior Decoration
