| Place of Origin: | China |
|---|---|
| Brand Name: | Sussman |
| Certification: | CE; ISO |
| Model Number: | SU-PH23 |
| Minimum Order Quantity: | 50 square meters |
| Price: | USD180-USD250 per square meter |
| Packaging Details: | plastic film |
| Supply Ability: | 500 square meter per week |
| Name: | Prefabricated Modular Home | Lifespan For Structure: | 90 Years At Less |
|---|---|---|---|
| Structure: | Galvanized Steel Frame | Floor Load Capacity: | 250-500kgs/sqm |
| Sound Resistant: | 10-15dB Can Reach 4 Start Hotel Standard(40dB) | Wind Resistant: | 12 Grade |
| High Light: | modern prefabricated modular homes,light steel structure house |
||
Steel Material House For Worker Labor Camp Light Steel Frame Prefabricated House Prefabricated Modular Homes
Light Guage Steel House is more stable than the one that made of welding frame steel . Besides, it is cheaper, more economic. With long lifespan, which can last a50-70 years, all the materials of light guage steel House is Q550. It is locked with bolts, which can be used repeatedly without any maintenance.
Light steel is 100% recycling,steel in the people is great significance.Good performance of the walls and roof combination, provide excellent thermal insulation, sound insulation, waterproof,compared with the traditional brick structure energy consumption reduced by 65%.Can effectively control air pollution,soil pollution,water pollution and environment on the spot,and effectively reduce the generation of waste.
| A | Light Steel stucture Villa Material List(many other options available) | ||
| 1 | Cold-formed Aluminum coating steel | kg | AZ150,G550 |
| 2 | Accessories of steel structure | m2 | SGC440,Z275 |
| B | External wall system | ||
| 1 | Fiber cement wood grain board | m2 | 3000*210*8mm |
| 2 | Vapor barrier | m2 | |
| 3 | OSB board | m2 | thickness:12mm |
| 4 | Wall fiber glass insulation | m2 | 100mm, 16kg/m3 |
| 5 | Gypsum board (inside of external wall ) | m2 | 2400*1200*12mm |
| 6 | Dry finish | m2 | |
| 7 | Waterproof material | m | 1.2mm |
| C | Internal wall system | ||
| 1 | Gypsum board | 2400mm*1200mm*12mm | |
| 2 | Fiber cement board (kitchen and bathroom) | 2440*1220*10mm | |
| 3 | Wall fiber glass insulation | 100mm, 16kg/m3 | |
| 4 | Dry finish | ||
| D | Roof & Ceiling system | ||
| 1 | Steel roof | m2 | Colorbond |
| 2 | Zinc metal tile battens | kg | |
| 3 | Waterproof material | m2 | 1.2mm |
| 4 | OSB board | m2 | thickness:12mm |
| 5 | Roof fiber glass insulation | m2 | 100mm, 16KG/m3 |
| 6 | Gypsum board for ceiling | m2 | 2400mm*1200mm*12mm |
| 7 | Cornice and kitchen and bathroom ceiling | m2 | 0.5mm K-140 steel panel |
| 8 | Steel gutter system | m | |
| E | Doors and windows | ||
| 1 | Exterior safety door | m2 | |
| 2 | Interior MDF door | set | |
| 3 | Aluminum glass sliding door | m2 | Australian Standards/EU standards |
| 4 | Aluminum glass windows | m2 | Australian Standards/EU standards |
