| Place of Origin: | China |
|---|---|
| Brand Name: | Sussman |
| Certification: | CE; ISO |
| Model Number: | SU-LG16 |
| Minimum Order Quantity: | 50 square meters |
| Price: | USD180-USD250 per square meter |
| Packaging Details: | plastic film |
| Supply Ability: | 500 square meter per week |
| Name: | Prefabricated Light Steel Frame House / Luxury Prefab Villa | Steel Frame House: | Steel Structure + Sandwich Panel |
|---|---|---|---|
| Wall System: | Cement Board+glass Wool+gypsum Board | Insulation System: | 90/100mm Glass Wool, XPS Panel |
| Roof: | EPS Sandwich Panel+glass Wool, Glaze Tile | Wind Loading: | <35m/s |
| High Light: | modern prefabricated modular homes,light steel frame homes |
||
Chile Project Light Steel Stud Modern Modular Prefab House Design Modular Prefab House
The light steel structure villa is a building with external wall board and internal wall board insulation blocks, The light steel villa is composed of a structural system, a ground system, a floor system, a wall system and a roof system. Each system is composed of several unit modules, which are manufactured in the factory, and assembled by unit modules on the site.Light steel villa cold rolled hot galvanized or galvanized thin wall steel as the main load bearing structure, combined with thermal insulation, sound insulation, waterproof, fire protection and other maintenance materials, to build a functional diversity, energy-saving and environmental protection of the building.Its housing components can all be produced on a large scale in the factory, and only assembly operations are needed on the site, which realizes the factory prefabrication of components and on-site assembly construction of houses. It is a mature integrated housing system at present, and also the development direction of future housing construction.
| Part | Name | Specification |
| Steel Structure System | Cold-formed thin wall steel/Q550 | 0.8-1.5mm thickness |
| Wall System | Decoration Panel | Metal or PVC decoration panel |
| XPS panel(Grade B1) | 1220*600*40mm | |
| Moistureproof paper | 50m2/coil | |
| OSB board |
6mm/9mm/12mm/15mm, conform to EU EN300 standard. |
|
| Inner wall-- interior gypsum board | 1220*2440*9mm | |
| Roof System | Roof Tile | Asphalt tile/Resin tile+SBS+OSB+Glass Wool |
| Insulation System | Wall,roof ,floor and ceiling | 90/100mm glass wool, XPS Panel |
| Doors & Windows | Entry door | Steel security door, can be customized |
| Interior door | Composite door, can be customized | |
| Aluminum alloy door | Glass sliding door, can be customized | |
| Window |
Plastic steel or Aluminum Alloy Window, double- layer glass |
|
| Ceiling System | Gypsum Panel + insulation cotton | 90/100mm glass wool |
Applications
1. Residence
2. Tourist and holiday house
3. Family house
4. Government residential project
5. Real estate development project
6. Constructions for other purpose
