B2 Fireproof Aluminum Composite PU Sandwich Thermal Insulation Panels

Basic Information
Place of Origin: Wuxi, China
Brand Name: Sussman
Certification: CE, ISO9001
Model Number: SM-SP023
Minimum Order Quantity: 500m2
Price: USD7 per m2
Packaging Details: Paper package
Delivery Time: 5-8 working days
Supply Ability: 1000m2 per day
Product Name: Polyurethane Foam Sandwich Panel,PU Sandwich Panel Width: 383mm
Fireproof: B2 Thickness: 16mm
Advantage: Fire Proof,Light Weight&Easy To Install Length: 3000mm-6000mm
High Light:

B2 PU Insulation Panels


B2 pu foam panel


Fireproof pu insulation board

B2 Fireproof Aluminum Composite PU Sandwich Thermal Insulation Panels
Significant energy saving effect
1,The integrated system of metal carving board mainly has the following four core energy-saving technologies: special aluminized zinc steel plate, rigid foamed polyurethane, reflective film, and air layer.
2,The base plate of the metal carving board is made of aluminized zinc steel plate with a thickness of 0.27-0.30mm. The surface is greatly enhanced by the principle of pressure balance, and the decorative effect is greatly improved. The decorative surface can be pressed into a variety of different styles of textures. It can meet the decoration needs of different grades, enhance the image of the building's facade, and inject new vitality into the appearance of the building. More effective saving of energy reuse. (Theoretical life of galvanized steel sheet is more than 45 years, and the recovery rate is 99.9%)
3,The intermediate insulation layer adopts rigid foamed polyurethane, which is currently the most technologically advanced and most environmentally friendly insulation material in the world, more effectively ensures that the metal carved panel wall energy-saving system maintains a long-term stable and good thermal insulation and energy-saving effect.
4,The unique design structure of the metal carved panel wall energy saving system completely eliminates the "thermal bridge" effect. The unique air layer can adjust the humidity of the wall, effectively avoiding indoor humidity and mildew. At the same time, because the metal carved panels are placed on the outside of the building's maintenance structure, structural damage caused by natural factors such as wind, sun, rain and snow is avoided, thereby extending the service life of the building.

Product Details
Material: Decorative Wall Panel metal pu Panel is made up of three layers: the top material is embossed metal board coated with Alu-zinc,
the middle is fire-safe material and Polyurethane foaming and the back is glass fibre paper
Feature: Decoration, insulation, energy-saving, fire-safe , easy installation, etc.
Application: Decorative Wall Panel could be used on any structural buildings : brick wall, steel structure, cement wall,, wood wall etc for
decoration and insulation .
Weight.: 3.7kg/ m2
Panel Size: Length :3000-6000mm(standard length is 3800mm) width: 380mm, thickness : 16-50mm
Packing Size: 3840*420*150mm
Package quantity: 8 pcs/carton
Productivity: 2000 square meter/ day
Delivery period: 10-15 days
Export Markets: Middle East, Europe , South America ,Asia etc.

B2 Fireproof Aluminum Composite PU Sandwich Thermal Insulation Panels 0
B2 Fireproof Aluminum Composite PU Sandwich Thermal Insulation Panels 1
Why we use sandwich panels?
1,The use of thermal insulation materials not only considers the level of thermal conductivity, but also measures the weight of different thermal insulation materials when the same thermal resistance is reached.
2,Safety: Because the surface of the metal carved board is a metal surface layer, it has a long service life and effectively prevents large areas of soil erosion caused by brick burning and quarrying.
3,High quality and stable performance: The metal carving board manufacturing process is all completed by CNC automated production line, with stable chemical structure and physical structure, and the product qualification rate reaches 99.9%.
4,Low maintenance cost and long service life: The service life of the aluminum-zinc steel plate used in the metal carving board substrate can reach more than 45 years after foreign research.
