Beach Portable Light Gauge Steel House Prefabricated 3 Floors Free Design

Basic Information
Place of Origin: China
Brand Name: Sussman
Certification: CE; ISO
Model Number: SU-LV
Minimum Order Quantity: 50 square meters
Price: USD180-USD250 per square meter
Packaging Details: plastic film
Supply Ability: 500 square meter per week
Type: Portable House Prefabricated Villa Wind-proof: Maximum 60 Meters Per Second
Snow Resistance: Maximum 2.9KN/M2 As Required Buiding Height: Max 3 Floors
Certificate: CE/ISO/SGS Anti-seismic: 7 Degree
High Light:

light steel frame homes

,

modern prefab modular homes

Light Gauge Steel Structure Frame Beach Portable House Prefabricated Villa With Free Design



Advantages:

(1). Environment protective, no garbage caused
(2). Doors, windows and interior partitions can be flexibly fixed
(3). Beautiful appearance, different colors for the wall and roof.
(4). Cost saving and transportation convenient
(5). Anti-rust and normally more than 15 years using life
(6). Safe and stable, can stand 8 grade earthquake.



1. Main Steel Frame
Steel column Fabricated by Q235 or Q345 Steel, 80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting.
Triangular Steel structure roof Fabricated by Q235 or Q345 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting.
Roof Purlin Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting.
Ordinary bolt 4.8S, Galvanized
2. Roof and Wall
Roof Panel

A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm


B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 120Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass:40Kg/m3, 60Kg/m3

Wall Panel

A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm


B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 120Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass:40Kg/m3, 60Kg/m3

Edge Cover 0.4mm galvanized color steel , angle Alu.

Fasteners &

Accessoreis

Nailsglue ect
3. Ceiling&Flooring
Ceiling 6mm gypsum board,with steel keel
Plywood 18mm film faced plywood
Floor feather 1.5mm PVC floor leather
Door and window
Door (1) External door: Single open door. Insulated with opening dimension 950*2100mm, furnished with lock with 3keys.
(2) Inner door: Single open door. Insulated steel door.
Window 4mm glass PVC window witn flying screem
4. Electrical System
Electric Cable (1) Three diferent color.
(2) Lighting: 2.5m m2.
(3) Air condition: 4.0mm2.
(4) BV cable, solid core.
PVC Wire Channel PVC wire channel
Lights Double tube fluorescent lamp, 220V,50-60HZ
Switches Single Switch, with junction box
Socket 16A five hole univesal socket.
Power Distribution Cabinet Box+breakers+earth leakage protective device
5. Water&Plumbing system(choose)
Water drain pipe (1) PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.
(2) Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC
Sanitary ware (1) Western Close tool: ceramic, with pipes and installation fittings
(2) Urinal: ceramic, with pipes and installation fittings
(3) Wash basin: ceramic, with post, faucet, pipes and installation fittings
(4) Shower head, Shower base, Water mixture
6. Plumbing System and Rain Water Drainage System as per building design





Beach Portable Light Gauge Steel House Prefabricated 3 Floors Free Design 0Beach Portable Light Gauge Steel House Prefabricated 3 Floors Free Design 1Beach Portable Light Gauge Steel House Prefabricated 3 Floors Free Design 2
