| Place of Origin: | China |
|---|---|
| Brand Name: | Sussman |
| Certification: | CE; ISO |
| Model Number: | SU-LH02 |
| Minimum Order Quantity: | 50 square meters |
| Price: | USD180-USD250 per square meter |
| Packaging Details: | plastic film |
| Supply Ability: | 500 square meter per week |
| Type: | Metal Frame Villa House | Main Structure: | C89 Light Steel Frame Keel |
|---|---|---|---|
| Wall Panel: | PVC Or Wood Side Panels | Fireproof: | American Stander OSB Panels |
| Dampproof: | Respiratory Paper | Design: | Vertex BD Softaware |
| High Light: | light steel frame homes,modern steel structure homes |
||
Cement Floor Custom Made Prefabricated Light Gauge Steel Structure Villa House Or Building
Our Vision:
To provide opportunities for the material and intellectual growth of all our employees, and through our joint efforts, contribute to the advancement of society and humankind.
Our Mission:
Building Smart house for the world!
| Building's Part | Description | Specification | ||
| Major Structure | Major Structure | Steel Frame | HANGANG Chinese Standard,G550-Z275 C-shaped Steel | According to design requirements |
| Consumables | Screw,bent parts,L parts,etc | According to design requirements | ||
| Roof | Deco Layer | Fiberglass reinforcement asphalt shingle | Standard 3mm thick | |
| Ceiling Insulation | Glass wool blanket | 100mm thick,18kg/m³ | ||
| Structural Layer | Oriented Strand Board | 1220*2440*12,waterproof type | ||
| Waterproof Layer | Waterproof roll | Two-sided Pressure Sensitive Adbesive SBS Sticky Roll | ||
| Cornice | Oriented Strand Board | 1220*2440*12,waterproof type | ||
| PVC cornice closure plate | white | |||
| Outer Wall | Outer Deco Layer | Vantilation Shutters | Vantilation | |
| Fiber-cement stack plate | 3600*210*8 | |||
| Filled Layer | Glass wool blanket | 100mm thick,18kg/m³ | ||
| Insulating Layer | XPS extruded polystyrene board | Grade B1,1200*600*50 | ||
| Rough Groud | Rough ground | antiseptic treatment,40*50 | ||
| moisture proffing course | Lamininating films | 0.35mm,unidirection | ||
| Structural Layer | Oriented Strand Board | 1220*2440*9, | ||
| Interior Wall | Dry Area | Paper double drywall | 1200*2400*9.5, | |
| Wet Area | Monolayer cement fiber board | 1200*2400*10 | ||
| Floor | Floor | Oriented Strand Board | 1220*2440*18, | |
| Door & Window | Entry Door | Steel Security Doors | 900*2100 | |
| Window | Aluminum Alloy Window | Double Glass Insulation Window | ||
Applications
1. Residence
2. Tourist and holiday house
3. Family house
4. Government residential project
5. Real estate development project
6. Constructions for other purpose
