Custom Built Prefab Modular Homes For Cold Climates Residential Steel Structure

Basic Information
Place of Origin: China
Brand Name: Sussman
Certification: CE; ISO
Model Number: SU-PH16
Minimum Order Quantity: 50 square meters
Price: USD180-USD250 per square meter
Packaging Details: plastic film
Supply Ability: 500 square meter per week
Name: Prefabricated Houses Villa Lifetime: More Than 40 Years
Insulation: 50mm Glass Wool Material: Galvanized Light Gauge Steel
Window: PVC Window Door: Steel Security Door
High Light:

ready made prefab house

,

mobile prefabricated houses

Residential Steel Structure Building/ Steel Building Kits House/Prefabricated Houses Villa







1) Lifetime for structure: 100 years.


2) Earthquake resistance: mix more than 8 grades.


3) Wind resistance: max 60m/s.


4) Fire resistance: all the materials used can be fire resistance.


5) Snow resistance: max 2.9KN/m²as required.


6) Heat insulation: 100 mm in thickness can match 1 m thickness of brick wall.


7) High acoustic insulation: 60db of exterior wall 40db of interior wall.


8) Insect prevention: free from the damages by insects, such as white ants.


9) Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean






Building's Part Description Specification
Major Structure Major Structure Steel Frame HANGANG Chinese Standard,G550-Z275 C-shaped Steel According to design requirements
Consumables Screw,bent parts,L parts,etc According to design requirements
Roof Deco Layer Fiberglass reinforcement asphalt shingle Standard 3mm thick
Ceiling Insulation Glass wool blanket 100mm thick,18kg/m³
Structural Layer Oriented Strand Board 1220*2440*12,waterproof type
Waterproof Layer Waterproof roll Two-sided Pressure Sensitive Adbesive SBS Sticky Roll
Cornice Oriented Strand Board 1220*2440*12,waterproof type
PVC cornice closure plate white
Outer Wall Outer Deco Layer Vantilation Shutters Vantilation
Fiber-cement stack plate 3600*210*8
Filled Layer Glass wool blanket 100mm thick,18kg/m³
Insulating Layer XPS extruded polystyrene board Grade B1,1200*600*50
Rough Groud Rough ground antiseptic treatment,40*50
moisture proffing course Lamininating films 0.35mm,unidirection
Structural Layer Oriented Strand Board 1220*2440*9,
Interior Wall Dry Area Paper double drywall 1200*2400*9.5,
Wet Area Monolayer cement fiber board 1200*2400*10
Floor Floor Oriented Strand Board 1220*2440*18,
Door & Window Entry Door Steel Security Doors 900*2100
Window Aluminum Alloy Window Double Glass Insulation Window



Custom Built Prefab Modular Homes For Cold Climates Residential Steel Structure 0Custom Built Prefab Modular Homes For Cold Climates Residential Steel Structure 1Custom Built Prefab Modular Homes For Cold Climates Residential Steel Structure 2
